16A-2 15 TOOTH - DOUBLE SIMPLEX SPROCKET - IND. HARD. TEETH
.jpg)
Details
| Roller Chain number | Chain No. | 16A-2 | |
| Pitch x Width | PxW | 1'' x 17.02mm | |
| Number of teeth | Z | 15 | |
| Outside diameter | de | 133,0 | mm |
| Pitch diameter | dp | 122,17 | mm |
| Tooth width | B1 | 16,2 | mm |
| Bore diameter | D1 | 24 | mm |
| Center distance between plates | A | 47,8 | mm |
| Hub diameter | C | 95 | mm |
| Sprocket width | L | 64 | mm |
