Carbonated Soft Drinks Production Line Glass Bottle Gas Water Filling Machine
Chat Now!
Send Inquiry- Product Details
- Company Profile
The machine is mainly used in the beverage filling operations,The three functions of bottle washing ,filling and capping are composed in one body of the machine.The whole process is antomatic.The machines is used to fill carbonated drink in bottles made of polyester and plastics ,The machin is convenient to adjust the machine to fill various types of bottles ,The filling operation is faster and more stable due to the isobar filling operation of the new type is adopted,The output and benefit of the machine is higher than the machines with same specifications,The advanced OMRON programmed controller(PLC)is adopted to control the machine running antomatically,air conveyor system is adopted in bottle entry section and belt conveyor system is adopted in bottle exit section,which can adjust speed and coordinated with transducer of the main machine to make the operations of moving bottle forward steadily and reliably,It is convenient to operate with higher antomation due to every parts of the machine is inspected to run with photoelectric detector,The machine is idea-preferred equipment for beverage makers.
Carbonated Soft Drinks Production Line Glass Bottle Gas Water Filling Machine
Structural Features:
1. Using high-precision mechanical filling valve, with cylinder liquid level and the back pressure controlled by a variable
signal proportional. Fast, stable, accurate, to be vacuum one at a time.
2. Stainless steel plunger and mechanical stirring glandtype magnetic reasonable cap to ensure that the
gland is healthy and reliable. Hopper and the cap taking- cover, capping transmitted by magnetic. The
capping is reliable and automatic unloading, reducing the rate of broken bottles.
SPECIFICATIONS FOR DCGF32-32-10 Carbonated Drinks Filling Machine Washing heads 32 (diameter:φ720) Bottle size 330-2000ml, by order Filling valve heads 32 (diameter:φ720) Capacity 3000-3500BPH (500ml) Capping heads 10 (diameter:φ240) Aseptic air consumption 0.4m3/min(0.4～0.6Mpa)
Applicable bottle bottle height: 150～350mm CO2 consumption 180g/100L Diameter: Φ52～Φ84mm Vacuum pump 0.15m3/h Operating voltage AC 380V Blowing 0.6m3/h Controling voltage DC 24V Power Main motor 2.2 KW Filling machine 0.55KW Spray pump 0.37KW Vacuum motor 1.1KW Hopper motor 0 .18KW Electric Chain motor 0.37KW Overall dimension (L×W×H） 3600*2650*2350mm3 Weight 5500 Kg
.jpg)
.jpg)
.jpg)
.jpg)
1. Using high-precision mechanical filling valve, with cylinder liquid level and the back pressure controlled by a variable
signal proportional. Fast, stable, accurate, to be vacuum one at a time.
2. Stainless steel plunger and mechanical stirring glandtype magnetic reasonable cap to ensure that the
gland is healthy and reliable. Hopper and the cap taking- cover, capping transmitted by magnetic. The
capping is reliable and automatic unloading, reducing the rate of broken bottles.
| SPECIFICATIONS FOR DCGF32-32-10 Carbonated Drinks Filling Machine | |||
| Washing heads | 32 (diameter:φ720) | Bottle size | 330-2000ml, by order |
| Filling valve heads | 32 (diameter:φ720) | Capacity | 3000-3500BPH (500ml) |
| Capping heads | 10 (diameter:φ240) | Aseptic air consumption | 0.4m3/min(0.4～0.6Mpa) |
| Applicable bottle | bottle height: 150～350mm | CO2 consumption | 180g/100L |
| Diameter: Φ52～Φ84mm | Vacuum pump | 0.15m3/h | |
| Operating voltage AC | 380V | Blowing | 0.6m3/h |
| Controling voltage DC | 24V | | |
| Power | |||
| Main motor | 2.2 KW | Filling machine | 0.55KW |
| Spray pump | 0.37KW | Vacuum motor | 1.1KW |
| Hopper motor | 0 .18KW | Electric Chain motor | 0.37KW |
| Overall dimension (L×W×H） | 3600*2650*2350mm3 | Weight | 5500 Kg |
